Dahua 3MP Dönen Başlıklı (Pan & Tilt) Wi-Fi Dış Ortam Güvenlik Kamerası

1/3.2" CMOS

2304 (H) × 1296 (V)

0.01 lux@F2.0 (Color, 30 IRE)

0.001 lux@F2.0 (B/W, 30 IRE)

0 lux (Illuminator on)

2 (Multi-core (IR + warm) light)

Pan: 0° to 345°
Tilt: 0° to 90°

2.8mm

F1.6mm

H: 96°; V: 54°; D: 112°

Vehicle Detection

H.265; H.264; H.264H; H.264B; MJPEG (Only supported by sub stream)

Main stream: 2304 × 1296@15fps

sub stream: 640 × 360@15fps
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

H.264: 32 kbps–6144 kbps;
H.265: 32 kbps–6144 kbps

WDR

DWDR

OFF/ON (4 areas, rectangular)

0°/180°

G.711a; G.711Mu; PCM

RJ-45 (10/100 Base-T)

Wi-Fi

IEEE 802.11b/g/n/ax 2.4000~2.4835 GHz, 2.4G,≤20dBm

ONVIF (Profile S & Profile G & Profile T); CGI

Smart PSS Lite; DSS; DMSS

CE

12 VDC (±30%)

Basic: 1.8 W (12 VDC)

Max.: 9.8W (12 VDC) (illuminator intensity + speaker on + PT rotation + Wi-Fi pulling stream + WDR)

–30 °C to +55 °C (–22 °F to +131 °F)

IP66

Reset button

125.4 mm × 110 mm × 140.3 mm (4.94" × 4.37" × 5.52") (L × W × H)
